Оптичний лінійний термінал Raisecom ISCOM5508-GP


Опис оптичний лінійний термінал Raisecom ISCOM5508-GP


SCOM5508-GP – 1U 19 “OLT (оптичний лінійний термінал) для мереж GPON малих і середніх операторів зв’язку. Устройсва є шасі для установки в нього плат з різним функціоналом. Володіє підтримкою змінних блоків живлення AC 220 Вольт і / або DC -48 Вольт або DC +24 Вольт. Замінюваний блок вентиляторів. Підтримується до 8 GPON одноволоконних WDM інтерфейсів для підключення клієнтських ONU, до 10 портів GE SFP і 2 порту 10GE SFP + для uplink.
ISCOM5508-GP підтримується наступні функції: 4096 міток VLAN, QinQ, Selective QnQ, 32K MAC, ACL, QoS, RADIUS, TACACS +, DHCP Relay Option 82 / DHCP Snooping, ARP Inspection, Storm-Control, IP Source Guard, Port Security MAC, Prevent DOS Attacking, Triple churning, P2P access control, Port isolation (Traffic Segmentation), STP / RSTP / MSTP, ITU-T G.8031 / G.8032 ERPS, LLDP, LACP, MVR, IGMP Snooping і ін
ISCOM5508 підтримує до 1024 ONU і є ідеальним рішенням для розгортання GPON мережі в секторі з невеликою щільністю абонентів, наприклад, в котеджному селищі. Підтримується віддалене управління по SNMP, а так само за допомогою графічної програми управління Raisecom NView NNM.

Характеристика оптичний лінійний термінал Raisecom ISCOM5508-GP


System Capacity
  • MTU: 9k byte (default 1,526 byte)
  • Switching capacity: 96Gbps bi-directional
  • Backplane bandwidth: 28Gbps bi-directional
  • Up to 32K MAC
PON
  • DBA in FIR, BIR or PIR modes with 64kbps granularity
  • Link test diagnostic
  • Provisioning, management and monitoring of remote ONTs
  • ONT registration modes: SN, password, SN + password
  • Bi-directional FEC
Ethernet
  • Support 4,094VLANs (C-tag), stacked VLANs (QinQ, S-tag),
    VLAN mapping, 1: 1 inner/outer VLAN translation and VLAN preservation
  • Interface protection, port monitoring
  • Transparent relay of BPDU, LACP, LLDP and STP
  • Support IGMP snooping v1/v2/v3, MVR, MVR proxy, and 1K capacity
IP Services
  • ARP
  • DHCP relay, snooping
  • IPv4, IPv6 (ACL, DHCP, MLD and interface)
Traffic Management
  • Service classification per port/VLAN/CoS (DSCP)
  • Support SP, WRR, DRR and SP + WRR scheduling modes, and up to 8 queues per port
  • Bandwidth profile based on port, VLAN, CoS, DSCP, and IP Precedence
  • Support flow-based filtering, redirection, mirroring, statics, policing and priority change
  • Support DBA and SLA
Security
  • ACL based on MAC, IPv4, IPv6, or user-define combinations, up to 2K
  • Support ACL map
  • Port-based mirroring, point-to-multipoint mirroring
  • Support IP Source Guard, Dynamic ARP Inspection, and Anti-DDoS
  • RADIUS, TACACS +
  • Storm control (broadcast, multicast, DLF)
Reliability
  • Link aggregation group (LAG) – up to 32 groups with 8 GE in each group,
    and six load balancing modes based on source/destination IP and/or MAC
  • Support STP, MSTP, RSTP
  • Port backup/isolation/protection
  • Ethernet ring protection with a switchover time less than 50ms
  • Port -based Ethernet local loop detection
  • Fault propagation
Ethernet OAM Dying gasp message in case of power failure
Auto-Provisioning
  • IEEE 802.1x port authentication
  • Easy generation and distribution of massive
  • configuration files using GUI-based toolkit
System Management
  • Remote management via SNMP v1/v2c/v3, Telnet and SSH v1/v2
  • Local management via console interface
  • KeepAlive, RMON, LLDP, Syslog
  • Port/VLAN/Cos-based statistics
  • Alarm management
  • SFP digital diagnostic management (DDM)
  • FAN, CPU monitoring
  • Voltage and temperature monitoring
Standard Compliance
  • IEEE802.1Q (VLAN), 802.1ad (QinQ), 802.1D (STP),
    802.1s (MSTP), 802.1p (CoS Priority), 802.1x (Security),
    802.3 ad (LAG), 802.3ah (EFM), 802.1ag (CFM)
  • ITU-T G.984 (GPON), Y.1731
  • IETF RFC 1213 (DHCP), 1493 (Bridge MIB), 2865 (RADIUS), 2 819 (RMON)
  • IGMP v1/v2/v3
  • RMON I and II standards
  • SNMP v1/v2c/v3
  • DHCP v4/v6
  • CE and RoHS compliant
Weight and power consumption Weight

  • Standard configuration
    • DC: 5.0 kg
    • AC: 5.3 kg
  • Full configuration
    • DC: 5.6 kg
    • AC: 5.9 kg

Maximum power consumption

  • Standard configuration
    • DC: 41 W
    • AC: 44 W
  • Full configuration
    • DC: 61 W
    • AC: 65 W
Dimensions of the chassis 440 mm (Width) × 266 mm (Depth) × 44 mm (Height) (without brackets)
